Main Features:
Adopts the synchronous belt drive instead of Gear drive;
Machine running more quite, higher printing precision, good quality;
Machine more stability;
High Mechanical speed: 135m/min
High printing speed: 30-120m/min ( match chamber doctor blade)
Single unwind & Single rewind
Technical Parameter :
| Model | WT-B8600 | WT-B8800 | WT-B81000 | WT-B81200 |
| Max. Material width | 630mm | 830mm | 1030mm | 1230mm |
| Max. Printing width | 560mm | 760mm | 960mm | 1160mm |
| Printing length | 7.5”–40”（190-1060mm） | |||
| Printing cylinder way | Hydraulic control up and down | |||
| Drive type | Synchronous belt drive | |||
| Printing material | Film, HDPE. LDPE, LLDPE etc | |||
| Mechanical speed | 110m/min | |||
| Printing speed | 10-90m/min | |||
| Anilox roller | Metal:100-300LPI / Ceramic: 200-800LPI | |||
| Doctor blade | Open type doctor blade | |||
| Register precision | Longitudinal：±0.2mm, crosswise：±0.2m | |||
| Unwind/rewind dia. | Φ1000mm | |||
| Dry system | Electric heating | |||
| Machine power | 40kw | 40kw | 45kw | 45kw |
| Machine size
（L x W x H） |
5.4m×2.0m×4.0m | 5.4m×2.2m×4.0m | 5.4m×2.4m×4.0m | 5.4m×2.6m×4.0m |
Optional:
1) various size of Printing cylinder
2) Double unwinder/ rewinder
3) Automatic pneumatic loading
4) Automatic pneumatic unloading
5) Crane
6) PLC: taiwan brand
7) Enclosed chamber dr blade
8) video camera monitor
9) Motor register for all directions
Attention Please
Machines can be made according to customer’s requirement.
In order to offer you the exact correct Printing Machine, please always give us the printing specifications required as below
1 the materials specification
2 unwinding width, diameter, weight
3 printing colors
4 flexo print or gravure print
5 speed
6 sample printing
