It is used for producing vest bags and flat-opening bags with heat sealing cold cutting. The main motor adopts frequency conversion motor to save more electricity and regulate speed more freely. The Panasonic color code tracker with good performance makes the sealing and cutting length more accurate and the error smaller. It adopts PLC control to adjust length more freely and accurately.
It can run 4rolls in one time with high production speed max. 220pcs/min*4lines.
Main Technical Parameters
| Model No. | WTLQ-C500*2 |
| Width of bag making | 100-400mm |
| Length of bag making | 250-580mm |
| Bag making speed | 80-220pcs/min*4lines |
| Machine frame | 12mm thickness steel plate |
| Main motor | 1.5kw motor (China brand)
1.5kw inverter speed control(Delta, Taiwan) |
| Rear material feeding | 0.55kw motor part 0.75kw inverter simulation automatic feeding
Magnetic powder brake 4sets of rear feeding fans with curtains Lifted and lowered by cylinder 4sets materials shortage switches: Panasonic |
| Front material feeding part | 2kw servo motor feeding (China brand)
Touch screen (China brand) 2sets material blocking switch: Panasonic |
| Cutting knife | 2sets, using material of m32 from Germany |
| Copper knife | 8pcs heating tube in the middle, controlled by Temperature controller |
| Photocell | Panasonic Japan |
| Bearing | Front material feeding part: from japan
ear material feeding part and other bearings: from China |
| Electrical parts | Delixi brand, with 16kv Static Eliminator |
| Punching Unit
(Optional equipment for T-shirt type bags with extra cost) |
12mm thickness steel plate
5T pressurized cylinder : xunjie, Taiwan Other cylinders are made in china Driven by stepper motor, Touch Screen Complete motor control
|
| Overall dimension(L*W*H) | 7000*1750*1900mm |
| Total power | 25kw |
