WTRB-A500-800 Computer Control High-speed Vest & Flat Opening Rolling Bag-making Machine (Double layer)

Category : Plastic Bag Making Machine

Model : WTRB-A500-800 Computer Control High-speed Vest & Flat Opening Rolling Bag-making Machine (Double layer)

OnLine Service:

Print this Page	Bookmark this
Skype Online	E-mail Us
PDF Download

Prev Next

Description	Send Inquiry

WTRB-A500-800 Computer Control High-speed Vest & Flat Opening Rolling Bag-making Machine (Double layer)

Specifications:

This machine a specially-designed point-cut rolling dual-purpose for vest & flat bags, is controlled by a computer, the step(servo) setting length system reduces the sealing-cutting dimensions errors, and the installation of photoelectric eyes track help make the position of figure of printing bags accurately, the computer numerical control can be selected to adjust the length of bag the machine will automatically stop and sound a warning if there is something wrong with the printing bags.

Main Technical Parameters:

Model	WTRB-A500	WTRB-A600	WTRB-A800
Max. Width of bag-making(mm)	400	500	700
Max. length of bag-making(mm)	1200	1200	1200
Bag-making Thickness	0.008-0.15	0.008-0.15	0.008-0.15
Speed of bag-making(pc/min)	40-200	40-200	40-200
Power of motor(kw)	1.1	1.1	1.5
Electric Heating power	1.2	1.6	2.2
Packing Dimensions(L x w x h)mm	3600X1200X1700	3400X1300X1700	3600X1500X1700
Machinery weight (kg)	800	900	100
