Performance and Characteristics:
This machine is used for slitting and rewinding various large rolling materials such as paper,(20g/㎡-300g/㎡)cellophane paper, bill paper, double-face adhesive tape, PVC, weave material, non-woven of cloth, etc. Adopt A and B pneumatic shaft structure for rewinding. It adopts photoelectric automatic error correction adjustment system for unwind-ing, anomalistic materials will be easy slit.(or liquid press style sub-tense system)Equipped with automatic waste film blowing device.(vertical knife structure)Manual material loading for unwinding(or pneumatic automatic material loading)with taper cover style pneumatic shaft.(3’,6’)
Main configure
1) With EPC for unwinding use of gas sensor type, compared to the general accuracy of the correction to 0.2mm
2) aluminum roll adopt external indurations improve the durability of aluminum roll
3) Main power 7.5KW, increased the force of pulling material.
4) the use of cylinder-type pressure stick instead of the original springs, can be expected to make land more flat
5) three transition rolls with silicone rubber to prevent roll material sliding and cut down
6) slip shaft for rewinding, it will make each part of rewinding automatic-skid and the tension is more evenly
7) bearing all are imported bearings
8) main motor with Taiwan DELTA inverter , used to make machine more stable, account of meter is more accurate .
9) the structure adopt solid cast iron, so the machine running is more smoothly, difficult to swing
Main Technical Parameter:
Model
|
WTHS-B1100
|
WTHS-B1300
|
WTHS-B1600
|
Max.width of unwinding
|
1100mm
|
1300mm
|
1600mm
|
Max.diameter of unwinding
|
Φ1400mm
|
Φ1400mm
|
Φ1400mm
|
Min.width of slitting
|
20mm
|
20mm
|
20mm
|
Max.diameter of rewinding
|
Φ500mm
|
Φ500mm
|
Φ500mm
|
Max.Speed
|
200m/min
|
200m/min
|
200m/min
|
Precision of slitting
|
±0.2mm
|
±0.2mm
|
±0.2mm
|
Total Power
|
7kw
|
7kw
|
8.5kw
|
Suitable power supply
|
380V/50Hz
|
380V/50Hz
|
380V/50Hz
|
Weight(approx)
|
2100kg
|
2300kg
|
2600kg
|
Overall dimension(LxWxH)
|
2850x2150x1350(mm)
|
2850x2350x1350(mm)
|
2850x2650x1350(mm)
|
