WT6/8-200/300-G Rotary Weighing &
Packaging Line For Granule
Application:
WT6/8-200/300-G Rotary Weighing & Packaging Line For Granule composited by
rotary packing machine, 4-head
combination weigher, working platform, which is suitable for packing all kinds
of granules, such as washing powder, rice, chicken essence, monosodium
glutamate, seeds, sugar, fodder, sesame seeds etc…
Standard Configuration:
1. PLC control system.
2. Pneumatic components
3. Temperature control system
4. Vacuum pump
5. Output device
Optional Configuration:
1. Rotary packing machine.
It is optional to choose WT6/8-230 rotary
packing machine. Only one minute is needed to adjust the machine splint.
2. Four-head linear weigher
3. Working platform
4. Material conveyor
5. Dust exhaust device
6. Vibration feeding device
7. Metal detector
8. Weight sorting scales
9. Product conveyor
Main Advantages:
1. To reduce production cost and
administration cost. One packing line can deduct 4-10 workers. Investment cost
can return with 1-2 years.
2. Product
quality is improved. The products achieve uniform standard from its appearance
or packaging quality.
3. To reduce the defect rate. Qualified product
rate reaches 99.5% to avoid artificial packaging waste.
4. To improve health standard. The packaging process
without direct contact with people to avoid man-made pollution.
Main Performance and Features:
1. A wide range of materials can be packed.
E.g.: kinds of shapes, state, or natures of granules.
2. Easy to operate. It adopts PLC control,
human-machine interface operating system, to make the operation easy and
intuitive.
3. Convenient to adjust. The replacement of
species can be completed within 10 minutes.
4. Suitable for different types of bags or
pouch.
5. A sound prevention system to protect
qualified product rate, to avoid waste of bags or materials.
6. The pack machine parts made of stainless
steel, to ensure the health and safety of materials and products.
7. High degree of automation. The whole
process of weighing and packaging is unmanned operation. Automatic alarm system
is adopted too.
8. Some imported engineering plastics without
refueling, to reduce the pollution of materials.
9. Oil-free vacuum pump is adopted to avoid
contamination of the production environment.
10. Waterproof
design can be rinsed with water, to reduce cleaning difficulty, and increase
the machine life.
Main Technical Parameters:
6-Station Rotary Weighing & Packaging
Line For Granule
Model
|
WT6-200-G
|
WT6-230-G
|
WT6-300-G
|
Pouch Type
|
Flat bag, 3-side sealing bag, 4-side
sealing bag, zipper bag, standup bag etc…
|
Pouch Material
|
Laminated film, PP, PE etc…
|
Pouch size
|
W:80-210mm
L:150-300mm
|
W:80-230mm
L:150-300mm
|
W:150-300mm
L:150-300mm
|
Packing weight
|
5-1500g
|
5-1500g
|
5-1500g
|
Packing Speed
|
20-50Bags/Min (depends on the packing
material and filling weight)
|
30-60Bags/Min (depends on the packing
material and filling weight)
|
20-40Bags/Min (depends on the packing
material and filling weight)
|
Packing Accuracy
|
≤±1%
|
≤±1%
|
≤±1%
|
Power
|
3.5KW,AC380V,50HZ
|
3.5KW,AC380V,50HZ
|
4.2KW,AC380V,50HZ
|
Overall Dimensions (L*W*H)(mm)
|
2200*2000*3000
|
2200*2000*3000
|
2770*2400*3200
|
8-Station Rotary Weighing & Packaging
Line For Granule
Model
|
WT8-200-G
|
WT8-230-G
|
WT8-300-G
|
Pouch Type
|
Flat bag, 3-side sealing bag, 4-side
sealing bag, zipper bag, standup bag etc…
|
Pouch Material
|
Laminated film, PP, PE etc…
|
Pouch size
|
W:80-220mm
L:150-300mm
|
W:80-230mm
L:150-300mm
|
W:150-300mm
L:150-300mm
|
Packing weight
|
5-1500g
|
5-1500g
|
5-1500g
|
Packing Speed
|
20-50Bags/Min (depends on the packing
material and filling weight)
|
30-60Bags/Min (depends on the packing
material and filling weight)
|
15-30Bags/Min (depends on the packing
material and filling weight)
|
Packing Accuracy
|
≤±1%
|
≤±1%
|
≤±1%
|
Power
|
3.85KW,AC380V,50HZ
|
3.85KW,AC380V,50HZ
|
4.5KW,AC380V,50HZ
|
Overall Dimensions (L*W*H)(mm)
|
2600*2200*3000
|
2600*2200*3000
|
3200*2550*3350
|
