WT50-FP2600, WT55-FP2800, WT50-FP21000 Film Blowing Flexographic Printing Connect-line Set

Category : Film Blowing Machine

Model : WT50-FP2600, WT55-FP2800, WT50-FP21000 Film Blowing Flexographic Printing Connect-line Set

OnLine Service:

Print this Page	Bookmark this
Skype Online	E-mail Us
PDF Download

Prev Next

Description	Send Inquiry

Main Features:

This machine adopts film blowing and flexographic printing connect-line to finish the film blowing and printing in one process, which realizes reducing the cost of labor, electricity, raw material, and factory area occupation.

Optional Equipment:

1) Auto loader and Dryer
2) Cast aluminum heater
3) Air shafts
4) Die rotary device
5) Up and down traction unit

6) Alloy steel screw

7) High-speed manual net changer

8) Auto tension controller for rewinding

Main Technical Parameters:

Model	WT50-FP2600	WT55-FP2800	WT65-FP21000
Raw material	LDPE.HDPE.LLDPE	LDPE.HDPE.LLDPE	LDPE.HDPE.LLDPE
Screw diameter	50mm	55m	65mm
Screw ratio (L/D)	28:1	28:1	28:1
Main motor power	11Kw	15Kw	18.5Kw
Max output	35kg/h	50Kg/h	65Kg/h
Die head diameter (mm)	φ60、φ 100	φ80、φ150	φ100、φ200
Blow film width	600mm	800mm	1000mm
Blow film thickness	0.01-0.08mm	0.01-0.08mm	0.01-0.08mm
Printing mode	Flexographic printing	Flexographic printing	Flexographic printing
Max. printing colors	2 colors	2 colors	2 colors
Max. web width	600mm	800mm	1000mm
Max. effective printing width	580mm	780mm	980mm
Range of repeat printing length	190～960mm	190～960mm	190～960mm
Max printing speed	50m/min	50m/min	50m/min
Plate thickness	2.38mm	2.38mm	2.38mm
Printing precision	±0.25mm	±0.25mm	±0.25mm
Total power	28Kw	32Kw	40kw
Weight	3.5T	4T	5T
Overall dimensions	6000 x 2400 x 4000mm	6200 x 2600 x 4300mm	6400 x 2800 x 4800mm
