Model

WT-SF-A (Basic type)

WT-SF-B (Practical type)

WT-SF-C (Enhanced type)

Raw materials of the machine adapt to

OPP, PET, PA, CPP film and other types of plastic film and paper, etc.

Width of material

800mm, 1000mm, 1100mm, 1300mm, 1600mm, 1800mm

Max. mechanical speed

150m/min

Max. Speed of laminating

120m/min

Operation or control system

Potentiometer

Buttons

PLC

Mode of unwinding and rewinding

Single shaft,

Or double-station rotary rollers for unwinding

Diameter of unwinding and rewinding

600mm-1500mm

Unwinding brake

Magnetic powder brake or air brake

Tension controller

Automatic constant tension control for unwinding, torque motor or variable frequency motor for rewinding

Edge position system

E.P.C or L.P.C automatic edge system, control accuracy≤1mm

Coating modes

Cob-webbing rollers coating,

Three-roller, steel wire, comma coating, or anti-comma coating

Oven

Side-opening or bottom opening door type

Arc top-opening door type (controlled by pneumatic system)

Arc top-opening door type (controlled by pneumatic system)

Temperature control system

PID intelligent temperature controller, temperature control accuracy≤±2℃

Electric heating controller

AC contactor

Solid-state contractor

Silicon-controlled rectifier

Reflector cover

Stainless steel

Stainless steel corridor

Optional

Rewinding controller

Torque motor

Variable frequency motor

Over-heating protection

All the motors of the fans are equipped with over-heating protecting system

Alarm of density of combustible gas

Without

Optional

Equipped

Other protecting system

Tension hold when machine stops, Static elimination
