This machine is suitable for the double-layer or multiple-layer lamination of such roll film material as BOPP, PET, Nylon, CPP, CPE, aluminum foil and paper, etc.

Characteristics:

1.    Whole machine controlled by PLC, with high running reliability and stability.

2.    In-touch screen man-machine interface, 10.4’’.

3.    Import vector eight motor synchronization control.

4.    Anilox roller with doctor blade for coating, various of anilox rollers available for different coating amount.

5.    Turret type unwinding station with EPC and auto splicing system with pre-driver, high speed non-stop shaft exchange (special separated single shaft available for aluminum foil laminating).

6.    Turret type rewinding station with EPC and auto splicing system with pre-driver, high-speed non-stop shaft exchange.

7.    Movable doctor blade with pneumatic back pressure.

8.    Three independent constant temperature section drying system with separated heating station and hot air in feeding. Temperature is controlled automatically.

9.    Pneumatic lifting drying chamber and operating platform for web passing, active synchronous running leading roller inside drying chamber.

10.  Pre-heating before laminating, water cooling roller for laminated web.

11. Inflatable air shaft for web loading or unloading.

12.  Three rollers nip laminating method, laminating pressure more even to ensure higher peel strength.
