Three-layer Common-extruding Rotary Die Film Blowing Machine WT-3L1000 WT-2L1200 SJ-3L1500

Category : Film Blowing Machine

Model : Three-layer Common-extruding Rotary Die Film Blowing Machine WT-3L1000 WT-2L1200 SJ-3L1500

OnLine Service:

Print this Page	Bookmark this
Skype Online	E-mail Us
PDF Download

Prev Next

Description	Send Inquiry

Characteristics:
1.Die head is layer type spiral mandrel, continuous 360°rotation.
2.Screen pack changer design is reliable, safe in operation and change the fitter screen easier.
3.Various functional parts may be installed to the lies., such as length counting device, vertical cutting device, cooling water row pipe, film spreading roller, scrap collecting device.

Use:
The lines are designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.
It is optimum designed on the trounds of preference of analogous lines in foreign and home. The lines can be blown continuous 800/1500mm in fold width 0.08mm in the thickness packaging films, film has good insulation, for instance holding temperature, anti-humid, anti-breeze, anti-rain, anti-rust, insulation oxygen, oil resistive, and so used for light and heavy-duty packaging, for example fresh fruits, meat-feeding, salt vegetables, fresh milk, drink.

Main Technical Variables:

Model	WT-3L1000	WT-3L1200	WT-3L1500
Screw Diameter	ф55×2 ф60×1	ф60×2 ф65×1	ф65×2 ф70×1
Screw Ratio L/D	28:1	28:1	28:1
Screw Speed	15-150r/min	15-150r/min	15-150r/min
Main Motor Power	15Kw×2 18.5Kw×1	18.5Kw×2 22Kw×1	22Kw×2 30Kw×1
Extrusion Output(Single)	50kg/h	80kg/h	100kg/h
Range of Die	ф150 φ200	ф200 φ250	ф250 ф300
Single-sided Thickness of Film	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Max. Folding Width of Film	1000mm	1200mm	1500mm
Electric Total Capacity	76Kw	88Kw	102Kw
Overall Dimension	6600×4100×5000mm	6800×4300×6000mm	7000×4800×7500mm
Weight of Machine	4T	5T	6T
