Hydraulic Deep Embossing Machine CT-315B
Hydraulic Deep Embossing Machine CT-315B

Category : Deep Embossing Machine

Model : Hydraulic Deep Embossing Machine CT-315B

OnLine Service:

Print this Page Bookmark this
Skype Online E-mail Us
PDF Download
Prev Next
Description Send Inquiry

CT-200B, CT-315B Hydraulic Super Deep Embossing Machine
Ⅰ. Introduction:

Application: wine box, moon cake box, health care products boxes, shirt box, underwear box, table calendar, fruit box, special local product, luxury packaging, etc.

Some ordinary packaging immediately become worth double after using this technology, manifests the stereo feeling, feel and visual effect more high-end, atmosphere, high grade.

Design concept: low cost, high grade. Safety, easy to operate.

Special technology: three beam four-post, advanced push board system, the stability of the hydraulic unit, we also provide grain gallery.

Ⅱ. Machine Construction:

Machine frame adopt three beams four four-post run desktop, three beams are made of high qualified steel plate welding, cylinder block adopts 45 # (with round steel processing), stand column adopts of 45# steel with hard chrome plating surface achieve hardness of HRC55-52, piston rod adopts 45 # steel, the surface of plating hard chromium achieve hardness of HRC55-52 too.

Ⅲ. Security System:

1.    Support activity crossbeam has a second level of protection, slide will not happen when installed offset.

2. Equipment operation have to press the switch, reset the mobile station.

 3. Pressure system is adjusted by the pressure relay, safe and convenient.

Ⅳ. Dynamical System:

Hydraulic system adopts well-known brands, five-axis machining of high precision molding of two-way cartridge valve. Reasonable layout, compact structure, tubing connection preferred tubing grafted to reduce the occurrence of oil spills, hydraulic system has the function of the oil filter, ensure hydraulic system to work normal and stable

Ⅴ. Electronic Control System

Electrical system adopts PLC computer program control: the machine is equipped with point two types of process of jog and moving. The system is equipped with rotating button, can be to choose the right means of suppression techniques according to the technological requirements, time speed and pressure can be adjusted. Stroke control adopts the non-contact proximity switch, other electrical components adopt domestic well-known China product.

Ⅵ. Major Components:

PLC touch panel, servo motor and servo controller adopt Taiwan Delta brand. Ball screw, pressure relay, rails, etc. Hydraulic system adopts cartridge valve and magnetic valve, xial plunger pump, Main motor adopts China top brands, etc.

Ⅶ. Main Advantages:


Unique deep embossing technology

Twenty years of hydraulic experience, innovative design, the hydraulic control system and a good heating system to create high-quality deep embossing techniques.

Accuracy and more stable

High quality steel structure, ball screw, hydraulic oil filtration system has a filter function to ensure stable and accurate operation of the hydraulic system.

Efficient, safe, energy-efficient

Unique die board taken off and changing device to make the die changing more safe and convenient. Advanced power conversion device, so that the main motor reduce 11kw, energy savings of about 10 kilowatt hour per hour.

Paper positioning

Compared to the traditional way to put paper, efficiency doubled, reduce labor, and more secure.

Electric control system

Adopting computer program control, stroke using non-contact proximity switches, well-known electrical components products.

High-quality elements

Delta PLC touch screen, servo motor, servo controllers, ball screw, pressure switch, rails, etc.

Hydraulic system

Using well-known top brands, five-axis machining of high precision molding of two-way cartridge valve.

Oil cooling

Unique automatic oil temperature control system to ensure that the hydraulic system oil temperature normal, the equipment running smoothly, low fault, and longer life.

Accessible template

Unique interchangeable templates designed to make the changing and cleaning of Die more easier, faster and safe.

Production Process



Ⅷ. Main Technical Parameters:

Items

Unit

Model

Number of cylinders

PC

1

2

Master cylinder pressure

KN

200T

315T

Max. opening distance

mm

70-80

70-80

Slider stoke

mm

220

220

Max. working pressure

mpa

20

22

Working speed

HOUR

800-1200

800-1200

Table effective area

MM

850X650

1050X720

Main motor

KW

7.5

7.5

Total power

KW

15.5

18.5

Working voltage

V

380

380

Overall dimensions

MM

1700X2000X2100

1900X2100X2300

Weight

KG

7500KG

9500KG

Ⅸ. Products Samples:



Ⅹ. Other Functions


Hot Stamping

On the installation of electrical equipment and gold foil stepping roller device, your can have the hot stamping technology, good compatibility, and stability to make your products more beautiful.

Die Cutting

Die-cutting process is a function of the device can be owned, installed on a cutting board, can be applied to thick paper production operations, puzzles, PVC plastic die-cutting.

Ⅺ. Die / Mould Used on Deep Embossing Machine

Raw material: Zinc,

Board thickness: around 2mm as normal.

Capacity: one zinc die can emboss 100000 pieces of paper board as usual.

Zinc die has replaced the traditional copperplate. The cost is much reduced.
